Large Image :  Factory Price SC/APC Quick Connector Fiber Optic Connector

Product Details:
Place of Origin: Shenzhen
Brand Name: Fongko
Certification: SGS
Model Number: FKSA019-58
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: Negotiatable
Delivery Time: 3 days
Payment Terms: T/T
Supply Ability: 10000 pcs per 1 day

Factory Price SC/APC Quick Connector Fiber Optic Connector

Description
Product Name: SC/APC Connectors Fast Connector Use: Other, FTTH/Area Network/Test Equipment
Warranty Time: 1 YEAR Type: SC APC Fiber Optic Connector
Insertion Loss SM: Average 0.3dB, Max.0.5dB Return Loss: Max.55dB (SC/APC)
Fiber Mode: SM(singlemode), MM(multimode) Apply Cable Type: 2x3mm ,2.0, 3.0mm Cable
Length: 58mm
Highlight:

Quick Fiber Optic Connector

,

Factory Price Fiber Optic Connector

,

SC/APC Fiber Optic Connector

Ftth SC APC Connector Quick Connector SC Fast Connector

Fiber Optic Fast Connector also known as a field-installable connector or mechanical splice connector, is a device used to
connect optical fibers quickly and efficiently without the need for complex splicing equipment. These connectors provide a
reliable and cost-effective method to terminate fiber optic cables in the field.
Key Features:
* Ease of Installation: Designed for rapid field installation with minimal tools. The connector comes pre-polished, requiring only basic skills to terminate a fiber.
* Speed: Significantly reduces installation time compared to traditional fusion splicing, as it doesn’t require curing or epoxy.
* Reusability: Some models can be reused, allowing adjustments and reconnections.
* Low Loss: Provides acceptable insertion and return loss values for many applications, such as telecommunications, data networks, and FTTH (fiber-to-the-home) installations.
* Versatility: Available in different types to support various types of fibers (single-mode or multi-mode) and connector types (SC, LC, FC, ST).



model
FKSA019-58
country of origin
China
Product Type
Spiral Type
feature
Ceramic C-type groove structure, good sealing
length
58 mm
Return loss
Max 55db (SC/APC)
Insertion loss SM
Average 0.3dB, maximum 0.5db
Application Cable Type
2x3mm, 2.0, 3.0mm cable
Price version
Very good value for money quality type
