FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer

FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer
FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer

Large Image :  FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer

Product Details:
Place of Origin: Shenzhen,Guangdong,China
Brand Name: Fongko
Certification: Rohs, SGS, ISO
Model Number: FKEQU-427 GS-601
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiatable
Payment Terms: T/T, Western Union, L/C
Contact Now

FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer

Description
Product Name: Fiber Optic Fusion Splicing Machine Certificate: RoHS
Application: Optical Fiber Cable Splicing Operating Temperature: -25~+50℃
Typical Splicing Duration: 6 Seconds Heating: 15S
Motors: 6
Highlight:

core alignment fiber optic fusion splicer

,

automatic splice machine for fiber optic

,

FONGKO GS-601 fusion splicer with warranty

FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer
GS-601 implements industrial-grade CPU+FPGA structure of high-performance, completely fresh HD optical fiber microscope, imported high-speed motor and aluminum-magnesium alloy materials extensively. Compared with the old version, our start product, GS-601 lowers the size by 38%, the weight by 52%, the power consumption by 57%, but improves the speed by 60%, the environment adaptability by 80% and the reliability (MTBF) by 200%. You can get unprecedented fusion splicing experience.

Alignment method
6 motors core to core alignment
Applicable fiber
SM(G.652), MM(G.651), DS(G.653), NZDS(G.655), BIF(G.657)
Cladding diameter
80-150μm
Coating diameter
160-3000μm
Cleaved length
5-16mm ( coating diameter<250um)
16mm (coating diameter:250-1000um)
Typical splice loss
SM: 0.02dB；MM: 0.01dB；DS/NZDS/BIF: 0.04dB
Return loss
>60dB
Splicing program
40 groups
Operation mode
Manual/ Automatic
Auto-heating
Available
Typical splice time
6 seconds
Typical heating time
18 seconds for 60mm and 40mm shrinkable sleeves
Fiber magnification
250X(X or Y view), 125X(X and Y view)
Viewing display
Dual high sensitivity camera, 5 inch 800*480 LCD Touch Screen Monitor
Data storage
4000 groups data records
Loss evaluation
Available
Tension test
1.8~2.25N
Interface
GUI menu interface, easy for operation
Battery capacity
5200mAh Li-battery, 250 cycles splicing and heating
Power supply
Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V
Electrode life
More than 4000 ARC discharges, easy to replace
Data storage
Pluggable 8GB micro SD card
Terminals
USB 2.0 port, for software upgrading, records exporting
Operating
Altitude:0-5000m, Humidity:0-95%,Temperature:-10~+50℃; Wind:max 15m/s
Dimension/Weight
156mm(L)×141mm(W)×156mm(H) / 2.45kg (including battery)



.

FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer 0FONGKO FKEQU-427 GS-601 Machine Automatic Splice Machine Core Alignment Fiber Optic Fusion Splicer 1
