Product Details:
|
| Product Name: | Fiber Optic Power Meter | Certificate: | RoHS |
|---|---|---|---|
| Auto Off Time: | 10 Min | Wavelength Range: | 850/1300/1310/1490/1550nm |
| Optical Connector: | FC/SC/ST | Detector Type: | InGaAs |
| High Light: | Light Source FTTH Power Meter,Handheld FTTH Power Meter,Fiber Optical FTTH Power Meter |
||
|
OPM
|
|||
|
Wavelength
|
850nm±20nm/1300±20nm
|
1310/1490/1550±20nm
|
|
|
Fiber Type
|
62.5/125μm
|
9/125μm
|
|
|
Optical connector
|
FC/SC/ST
|
|
|
|
Laser Type
|
FP-LD
|
||
|
Power
|
≤-5dBm
|
||
|
Stability
|
±0.02dB/8h
|
||
|
Mode
|
CW/270Hz/1000Hz/2000Hz
|
||
|
Power Regulation
|
0~6dB,1dB Step
|
||
|
Others
|
|||
|
Power supply
|
Three AA Batteries/1500mA Rechargeable Lithium Battery (optional)
|
||
|
Battery continuous working time
|
≥72h(LS function)
|
||
|
Auto shutdown time
|
10min
|
||
|
Operating temperature
|
-10°℃-+50℃
|
||
|
Storage temperature
|
-40°℃-+70℃
|
||
|
relative temperature
|
0-95％ No condensation
|
||
|
Size
|
186mmx100mmx50mm
|
||
|
Weight
|
140g/150g
|
||
|
Ordering Information
|
|
|
FKEQU-084-A-B
|
|
|
A
|
B
|
|
LS Wavelength:
S:1310/1550nm M:850/1300nm
T:1310/1490/1550nm
SM:850/1300/1310/1550nm
Y:Customize
|
Battery:
D. dry battery; L. Lithium battery |
|
Selection instructions: the range of the power meter is required, and the others are optional
|
|
